Features
Combine DesignMax models to complete any design, big or small — 12 loudspeakers to mix and match, from 2-inch, low-profile models to 8-inch, high-SPL compression-driver loudspeakers and outdoor-rated options
Deliver rich lows and clear, intelligible highs with coaxial two-way drivers — no DSP or EQ required. For even better sound, use select Bose Professional DSPs and amplifiers to enable Bose Professional loudspeaker EQ and SmartBass processing, which expands performance and response at any listening level
Blend with any room design with elegant form factors, minimum-bezel grilles available in black or white, and removable logos
Reduce installation time with the patented QuickHold mounting system, which also reduces strain, hassle, and the chance of product damage
Install easily with industry-standard accessories — all models include Euroblock connectors; in-ceiling models include plenum-rated backcans, tile bridges, and front-access audio wiring that makes installation and troubleshooting easier
Deliver high SPL for demanding applications, including high-ceiling venues such as ballrooms, concourse, and convention cente
------------------------------------------------------ SPECS -------------------------------------------------
Frequency Response (+/-3 dB)
60 - 20,000 Hz
Nominal coverage (H x V)
135° conical
Power Handling, peak
600 W
Maximum SPL @ 1m
113 dB
Frequency Range (-10 dB)
52 - 20,000 Hz
Power Handling, long-term continuous
150 W
Sensitivity (SPL/1W @ 1 m)
91 dB
Nominal Impedance
8 Ω (transformer bypass)
