Features
Deploy as zone-fill to support ArenaMatch arrays systems, delivering powerful, intelligible sound and ensuring consistent tonal balance with EMB2S compression drivers in every speaker
Deploy to provide high-level foreground music in any outdoor venue
Install outdoors with an IP55 weather rating, three-layer stainless steel grille, water-resistant woofer cone coating, industrial polyurethane exterior coating, and molded cover to protect inputs
Adapt to a variety of configurations — all models ship standard with 70/100V transformer inputs and passive crossover with optimized filters for each transducer for more consistent frequency and polar response
Streamline the design process by combining with complementary Bose Professional products, such as PowerMatch amplifiers and ControlSpace DSPs
Provide wide, even coverage with 90° x 60° constant-directivity high-frequency horn, which can be rotated for horizontal or vertical installation
Perform in the most demanding applications with 70 Hz – 16 kHz frequency response and 126 dB maximum peak SPL
Support lowest vocal range with 2x Bose Professional LF8 8-inch woofers featuring a 2-inch extended-excursion voice coil, which extends response to 70 Hz
------------------------------------------------------- SPECS ----------------------------------------------------
Frequency Response (+/-3 dB)
80 Hz to 16 kHz
Nominal Coverage Pattern (H x V)
90° x 60°
Power Handling, peak
1200W
Maximum SPL @ 1m
119 db Free Field
121 db Wall/Ceiling
Nominal Impedance
8 Ω (transformer bypass)
Frequency Range (-10 dB)
70 Hz to 16 kHz
Power Handling, long-term continuous
300 W
Sensitivity
94 db Free Field
96 db Wall/Ceiling
Maximum SPL @ 1m, peak
125 db Free Field
127 db Wall/Ceiling
